Fiber Optic Components and Peripheral Products
SON-60N

Low-loss Multicomponent/ Borosilicate Glass Optical Fibers
SON-60N

A multi-component/ borosilicate glass fiber which has larger core size ratio, achieving a low transmission loss. Ideal for light guides for long distance, as well as telecommunication for short distance and in-vehicle.

Applications

  • Light guides for long distance
  • Telecommunication for short distance and in-vehicle

Structure

  • SON-60N(240/250FE)
    a:Core (µm) 240
    b:Clad (µm) 250
    c:Primary coating (µm) 275
    Epoxy resin

Properties

SON-60N
Numerical aperture (NA) 0.50
Opening angle (2θ) 60°
Core/Clad (µm) 240/250
Transmission loss ≦ 75dB/km
